EG-250 short centrifugal pumps, is hydraulic motor drive pump.
Because of short pedestal/pump frame, mainly used for narrow positions and oilfield fracturing truck.
Its performance is pretty same as Mission Magnum I pump.
Fluid end parts can be made to materials like alloy steel casting iron, stainless steel and aluminum bronze, etc.
Main technical specifications:
Model | Rotation speed r/min | Capacity m3/h | Pressure head m | Efficiency % | Motor HP kW |
10x8x14 | 1450/1750 | 260-300 | 33-35 | 65 | 75/90 |
8x6x14 | 1450/1750 | 240-260 | 33-35 | 65 | 55/75 |
8x6x11 | 1450/1750 | 180-230 | 24-26 | 65 | 37/45 |
6x5x14 | 1450/1750 | 180-220 | 26-35 | 65 | 37/45 |
6x5x11 | 1450/1750 | 160-200 | 22-28 | 65 | 30/37 |
5x4x14 | 1450/1750 | 100-150 | 26-33 | 65 | 22/30 |
4x3x13 | 1450/1750 | 60-90 | 26-30 | 65 | 11-22 |
3x2x13 | 1450/1750 | 40-60 | 25-30 | 65 | 5.5-22 |
