4x3x13 Centrifugal pump is mainly used as grouting pump, grouting mud to well bore or shaft when drilling and tripping, or used for mud delivery in other application.
Main technical specifications:
Impeller diameter | 280mm(11″) | 305mm(12″) |
Capacity | 60m3/h | 80m3/h |
Pressure head | 25m | 28m |
Efficiency | 65% | 65% |
Motor HP | 11kW | 15kW |
Motor rotation rate | 1450rpm | 1450rpm |
Inlet diameter | 4″ | 4″ |
Outlet diameter | 3″ | 3″ |
Weight | 395kg | 405kg |
Dimension/mm | 1530×495×675 | 1570×495×675 |
