Procedure for Checking Hydraulic Oil Level 1.Ensure that the pipehandler clamp cylinder is unclamped, the counterbalance cylinders are connected to the hook, the bail is resting in the hook, and the system power is OFF 2.Check to see that the hydrulic fluid level is at the middle of the sight glass 3.If the fluid is low, add hydraulic fluid (see the Lubrication and Maintenance section of this manual 4.Check the red “pop-up” alarm on the hydraulic filter for contamination 5.Replace the filter (P/N 114416-1) if the indicator has popped up 6.Use care to prevent contamination from entering the hydraulic system during maintenance activities
